INSTALLATION AND CONNECTION

Content of the package:

1. Complete hydromassage panel
2. Panel bracket straight
3. Panel bracket corner
4. Ceiling shower
5. Hand shower nozzle
6. Hand shower holder
7. Shower hose 150 cm
Before installation and connection of the panel, it is necessary to let polluted water and sediments drain out of
the piping in order to avoid clogging of strainers and subsequent damage to the shower head combination
faucet. Make sure that the panel fixing points are free from electricity, gas or water lines and pipings.
ASSEMBLY INSTRUCTIONS:
on a side wall
1.
Put the panel on the selected point in a way that the shower head is min. 195 cm above the tub bottom (above the floor),
or determine the height based on the optimum height of persons supposed to use the shower
2.
Check that the already prepared water supply can be connected to the panel in this position.
3.
Mark the bottom end of the panel on the wall, remove the panel.
4.
Use a water level to draw the vertical axis for panel placement in the center of the outlets.
5.
Draw the horizontal axis 50 mm from the marked bottom end of the panel, attach the "straight" panel bracket and mark
the fixing holes on the wall
6.
Check that the spacing between the panel suspension screws is 1800 mm
1800 cm from the bottom hanger and mark the fixing holes in a similar way.
7.
Drill Ø 8 mm holes and insert the dowels.
8.
Screw in the brackets with their fixing groove on top and adjust them using water level
9.
Prepare water connection, insert the washer with a strainer into the reinforced hose nut. Connect the cold water outlet
to the blue cold water inlet and the hot water supply to the red inlet
10.
Open the water supply, check the tightness of piping and correct connection.
11.
Hang the panel onto the grooves by slipping the M6 screws fitted at the panel ends to the edge of the slanted bracket
grooves and put the panel tightly alongside the wall by pushing it downwards.
12.
Fix the panel to the bracket by tightening the M6 nuts
You will not use the corner panel bracket and the M6x16 screws with nuts and washers.
ASSEMBLY INSTRUCTIONS:
corner installation
In case you install the Stream hydromassage panel to a corner, the steps are similar with the difference that, instead of
drawing the vertical axis, you will measure and install the fixing elements symmetrically to the corner.
1.
Draw the horizontal axis 50 mm on both sides from the marked bottom end of the panel, attach the "corner" panel
bracket and mark the fixing holes on the wall
2.
Having screwed in both "corner" brackets, use the M6x16 screws to fix the second "straight" bracket on them. Then
follow the same steps as in the previous case.
1 pc
2 pcs
2 pcs
1 pc
1 pc
1 pc
1 pc
(Fig. 4)
.
(Fig. 7)
8. Dowel Ø 8 mm
9. Dowel screw
10. Screw M6x16
11. Nut M6
12. Washer Ø 6 mm
(Fig. 2)
.
(Fig. 6)
.
.
- 8 -
(Fig. 1)
.
(Fig. 4)
. Draw the axis of the top bracket also
(Fig. 4)
.
4 pcs
4 pcs
4 pcs
4 pcs
4 pcs
