3.1 Teaching in the drive and first remote control
(will usually have been completed at the factory)
i No longer than 6 seconds may pass between two inputs.
Otherwise, the inputs will be deleted and must then be redone.
1. When using hand-held radio transmitters, remove the cover on the back to make
your adjustments.
Caution: Press down gently on the battery to keep it in place (making contact).
After making your adjustments, slide the cover back on.
When teaching in a multi-channel radio transmitter, use the P1 buttons on the
i
radio transmitter
to switch to the channel you want to assign for this drive before you perform
the next step.
2. Press and hold setting button A on the drive for approx. 3 seconds
=> The roller blind confirms this button press by beeping +
moving briefly once.
A setting button
B emergency charging socket for charging the battery
3. Press the P2 button on the radio transmitter once
=> The roller blind confirms this button press by beeping + moving
briefly once.
4. Press the P2 button on the radio transmitter once
=> The roller blind confirms this button press by beeping once.
5. Press the DOWN button on the radio transmitter once
=> The roller blind confirms this button press by beeping + moving
briefly six times.
3.2 Changing the drive's direction of rotation when the end positions are set
i
To change the direction of rotation again, repeat step 1.
1. Press and hold setting button A on the drive
=> The roller blind confirms this button press by moving
briefly three times at intervals of approx. 4 seconds +
beeping three times when the setting button is released.
A setting button
B emergency charging socket for charging the battery
3.3 Adjusting the top and bottom end position
(will usually have been completed at the factory)
i To adjust the end positions, they must first be deleted as described in 3.6 or
changed as described in 2.2.
1. When using hand-held radio transmitters, remove the cover on the back to make
your adjustments.
Caution: Press down gently on the battery to keep it in place (making contact).
After making your adjustments, slide the cover back on.
2. Press the P2 button on the radio transmitter once
=> The roller blind confirms this button press by beeping
+ moving briefly once.
3. Press the UP button on the radio transmitter once
=> The roller blind confirms this button press by beeping
+ moving briefly once.
4. Press the P2 button on the radio transmitter once
=> The roller blind confirms this button press by beeping
+ moving briefly four times.
5. Press the UP button on the radio transmitter once.
Optional: Approach the end positions in defined incre-
ments. You can use this extra function to help with your
adjustments if necessary. While the blind is moving UP,
press the P2 button on the radio transmitter once
=> The roller blind moves in defined increments.
6. Press the STOP button on the radio transmitter once
as soon as the blind reaches the top end position you
want.
7. Press the STOP button on the radio transmitter five times
=> The roller blind confirms that the top end position
has been programmed by beeping when the button is
pressed + moving briefly.
Edition 04.2022
Subject to technical changes I
8. Press the DOWN button on the radio transmitter once.
Optional: Approach the end positions in defined incre-
ments. You can use this extra function to help with your
adjustments if necessary.
While the blind is moving DOWN, press the P2 button on
the radio transmitter once
=> The roller blind moves in defined increments.
9. Press the STOP button on the radio transmitter once as soon
as the blind reaches the bottom end position you want.
10. Press the STOP button on the radio transmitter five times
=> The roller blind confirms that the bottom end
position has been programmed by beeping when the
button is pressed + moving briefly.
3.4 Setting the pinpoint operating mode (optional)
B A
1. When using hand-held radio transmitters, remove the cover on the back to make
your adjustments.
Caution: Press down gently on the battery to keep it in place
(making contact).
After making your adjustments, slide the cover back on.
2. Press the P2 button on the radio transmitter once
P2
=> The roller blind confirms this button press by beeping + moving
briefly once.
3. Press the UP button on the radio transmitter once
P2
=> The roller blind confirms this button press by beeping + moving
briefly once.
4. Press the DOWN button on the radio transmitter once
=> The roller blind confirms this button press by beeping +
moving briefly twice.
Pinpoint operation is performed by pressing the UP/DOWN button briefly at the
i
same time.
Press and hold the UP/DOWN button to move the blind continuously.
Repeat steps 2 to 4 to delete the setting.

3.5 Teaching in a third blind position (optional)

B A
You have an option to assign an extra stop position for the roller blind.
i
This position must be somewhere in between the two end positions.
1. When using hand-held radio transmitters, remove the cover on the back to make
your adjustments.
Caution: Press down gently on the battery to keep it in place (making contact).
After making your adjustments, slide the cover back on.
2. Press the UP or DOWN button to move the roller blind
into the position you want.
Press the STOP button.
3. Press the P2 button on the radio transmitter once
=> The roller blind confirms this button press by beeping +
moving briefly once.
P2
4. Press the STOP button on the radio transmitter once
=> The roller blind confirms this button press by beeping +
moving briefly once.
5. Press the STOP button on the radio transmitter once
=> The roller blind confirms this button press by beeping +
moving briefly three times.
P2
Press the STOP button for 3 seconds. The blind moves to the third blind position.
i
If pinpoint mode has been set, the blind first moves to the bottom end position
and then to the third blind position. Repeat steps 3 to 5 to delete the third blind
position.
STOP
P2
Solix Fix exterior roller blinds
Adjustment instructions
