Solix Fix exterior roller blinds

Installation instructions

Important information for installers and users
DE
1. Unpack the unit and check for any damage.
Do not install a damaged unit. Consult the specialist retailer first.
2.
Installation
To ensure the unit will be commissioned correctly and without any issues, we recommend charging the battery fully using the
MHZ charging cable prior to installation.
2.1
Qualifications
These installation instructions are aimed exclusively at qualified installers with extensive knowledge in the following areas:
– Health and safety at work and accident prevention regulations
– Handling of ladders and scaffolding
FR
– Handling and transport of long, heavy components
– Use of tools and machines
– Attachment of fasteners
– Assessment of the building fabric
– Commissioning and operation of the product
In the absence of any of these qualifications, a specialist fitting company must be employed to install the product.
2.2 Fastening materials
Caution: The blind is supplied without fastening materials.
The fitter must adapt the fastening materials to suit the type of construction and the substructure material in question.
NL
EN
ES
Unit height
up to 700 mm
from 701 mm to 1200 mm
from 1201 mm to 1700 mm
from 1701 mm to 2050 mm
from 2051 mm
42
IT
Drill holes for each side guide
Number of drill holes
2
3
4
5
6
Required tools:
Gr. 1
SW 2,0
Supplied parts:
optional
Subject to technical changes I
optional
Edition 04.2022
