DESCRIPTION OF THE DEVICE
Features
Powerful LED scanner with rotating gobos and 120 W LED
• Equipped with a 120 W COB LED
• Flicker-free projection
• 13 or 15 DMX channel mode selectable
• DMX-controlled operation or stand-alone operation with Master/Slave function
• Sound-controlled via built-in microphone
• Internal programs
• Color wheel with 8 dichroic color filters and white
• Rainbow effect with adjustable speed
• Gobo-wheel with 7 rotating gobos plus open
• Gobo shake function
• Rotating 3-facet prism
• Exact positioning via 16 bit PAN/TILT movement resolution
• Strobe effect with adjustable speed
• Motorized focus
• Electronic dimmer
• Fan-cooled
• Lightbeam with 14° radiation angle
• Control board with graphic LC display and four operating buttons for adjusting the DMX starting address,
PAN/TILT reverse
• Switch-mode power supply for operation between 100 and 240 Volts
• DMX control via every standard DMX controller
Overview
1
2
3
4
9
10
11
12
13
14
15
16
17
18
19
(1) Housing screw
(2) DMX indicator
5
(3) Error indicator
6
(4) Display
(5) Enter button
7
(6) Down button
8
(7) Up button
(8) Menu button
(9) Mounting bracket
(10) Mirror
(11) Objective-lens
(12) Fixation screw
(13) Safety eyelet
(14) Venting slots
(15) Housing cover
(16) DMX-In socket
(17) DMX-Out socket
(18) Power supply
(19) Fuseholder
23/34
00094159.DOC, Version 1.0
