TC-Kit (+)
5.1 Description of functions
The cooler is controlled by a microprocessor.
The programmable display shows the block temperature in
the selected display unit (°C / °F) (factory preset °C). Applica-
tion-specific settings can easily be configured guided by the
menu, using the 5 buttons. For one, this applies to the target
outlet dew point, which can be set from 2 to 20 °C (36 to 68 °F)
(factory setting 5 °C/41 °F).
And then the warning thresholds can be adjusted for low and
excess temperature. These are set relative to the outlet dew
point τ setting.
a
For the low temperature the range is τ
imum 1 °C cooling block temperature), for the excess temper-
ature the range is τ +1 to +7 K. The factory settings for both
a
values are 3 K.
The flashing display as well as a red LED on the display mod-
ule along with the status relay indicate the conditions are be-
low or above the configured warning range (e.g. after switch-
ing on).
The outputs are:
A potential-free status output. The relay is activated when the
block temperature is within the target range. The output also
serves as collective alarm for device faults, moisture ingress,
etc.
A switched output for connecting a gas pump. The output
uses the same relay as the status output. This output can only
be used for pumps designed for 24 VDC operating voltage.
Another relay output is available for switching up to two peri-
staltic pumps. The pumps are supplied with the mains voltage
and can be shut off via the device menu for maintenance pur-
poses.
The TC-Kit can optionally be configured for connecting a
heated line, which can be either self-regulating or a heated
line regulated by the cooler.
Operation via 115 VAC/230 VAC and using the regulator for a
heated line requires the optional expansion module.
BX440028 ◦ 06/2023
-1 to - 3 K (at a min-
a
5.2 Use of menu functions
Brief description of the operating principle:
The unit is operated using 5 keys. Their functions are:
But- Section
ton
Display • Switches from the measurement display
to the main menu
or
Menu • Selects the menu item displayed
OK
Enter • Applies an edited value or a selection
Display • temporarily switches to the alternative
measurement display (if option installed)
Menu • Back
Enter • Increase value or browse selection
• Note:
▪ Press button 1 x = changes para-
meter / value by one;
▪ Hold button = fast mode (numerical
values only)
▪ Display flashes: modified parameter/
value
▪ Steady display: original display/value
Display • temporarily switches to the alternative
measurement display (if option installed)
Menu • Next
Enter • Reduce value or browse selection
Menu • Move one level up
ESC
Enter • Return to menu
Changes will not be saved!
• Sets a menu to favourite.
F
(Note: The favourite menu will also be ac-
or
tivated with the menu locked!)
Func
5.2.1 Lock Menu
Some menus can be locked to prevent inadvertently changing
the settings of the unit. This requires setting a code. For in-
formation on setting up or disabling the menu lock please
refer to "Global Settings" (toP) under menu item toP > Loc.
The menu lock is not enabled at the time of delivery, all menu
items can be accessed.
With the menu locked, only the following menu items will be
visible without entering the correct code:
Menu item Explanation
toP > unit Temperature unit selection (°C or °F).
F or Func. Accessing the Favourites menu
NOTICE! This menu may be one that is nor-
mally locked.
Functions
