Operation

6 Operation
6.1

Control unit

6.1.1 Setting the floating state without load

The floating state without load must be set before commissioning.
The hovering state of the lifting device must be adjusted to the respective gripper weight. The position
of the flap (2) can be changed for this purpose When you place the suction pad on the load, the flap is
fully opened via the plunger. This allows the load to be sucked in and lifted.
Procedure:
•
Turn the adjusting screw (1) on the control unit (accessible from below)
•
The wider the flap is open, the lower the appliance floats
If the flap is fully closed, the appliance will suddenly shoot up as soon as the fan is switched
on!
•
Position the control unit centrally above the load and press
the control lever (1) down. The lifting unit relaxes and the
control unit lowers.
•
Place the control unit in the center of the load/curb.
•
Slowly push the control lever on the control unit upwards.
The load is sucked in and the lifting unit contracts.
The operating lever may be left in the "suction/lift" position for a maximum of 90 seconds, as
otherwise the fan may be damaged and fail (warranty void!) and energy is wasted
unnecessarily.
52300031
Turn clockwise ➔ Flap is opened further
o
Turn counterclockwise ➔ Flap is closed
o
13 / 18 GB
