Beschreibung
description
Focusmotor
focusmotor
Leuchtenhaube
light head cover
D.C. Motor
D.C. Motor
Bremsschraube
friction screw
Relingrohr
rail
Relinghalter
rail holder
Abschlußdeckel
endcover
Abdeckhaube
cover
Befestigungsschraube
screw for fixation
Tastaturaufnahme
key board frame
Schleifringkörper
sliding contact rings on central column
Stoßschutz
bumper
Bremssegment
friction segment
Kontaktblock
contact block
Kontaktblock
contact block
Autobloc-Magnetbremsen Auslösungsplatine
Autobloc-magnetic brake release board
Motorsteuerungslogik
motor control logic
Filterglasscheibe, 4500 K
filter glass disc, 4500 K
Filterglasscheibe, 3600 K, ThermoSorb
filter glass disc, 3600 K, ThermoSorb
Unterglas der Mittelglasgruppe, Standard, 4500 K
Lower glas of middleglas assy, standard, 4500 K
Unterglas der Mittelglasgruppe, Standard, 3600 K+ ThermoSorb
Lower glas of middleglas assy, standard, 3600 K + ThermoSorb
Mittelglasbaugruppe, Standard, ThermoSorb
central glass assembly, standard, ThermoSorb
Mittelglasbaugruppe, Standard, 3600 K
central glass assembly, standard, 3600 K
CHROMOPHARE
C 952 Service Manual (D, E)
®
Teile Nr.
part no.
50098
39453
39611
38821
39460
39483
40023
39638
37071
39339
38837
38819
39636
39693
39694
50379
39221
39496
39497
39495
51166
43053
54410
Abbildung auf Seite
description on page
21
21
21
21/22
21
21
21
21
21
21
21
22
22
22
23
23
24
24
24
24
24
25
25
15
