4.2

Assembly

Mounting version A
Mounting version B
Mounting version B permits to easily isolate the heat generation system without further shutoff
valves. Necessary accesories: gasket, fitting, pump fitting
Optional accessories for assembly into the ½" sleeves of the ball valves
Item no. 566001 Immersion sleeve (as a point for temperature measurement)
Item no. 2260 Valve with counter nut for draining the boiler circuit
B-10 999612x-mub-ml – V08
4 Assembly and installation [specialist]
2018/02
