Identify the Parts of the Prism III Printer
Operator Panel
The operator panel is located on the front of the printer. There are four
indicator lights and an operator button on the operator panel.
Operator Button
Press the operator button to open and close the printer tray. The Error
indicator light is in the center of the operator button. Refer to the
Lights
section below for more information.
Indicator Lights
The name and function of each indicator light is described below. Each
indicator light reflects different conditions on the Standalone Prism printer.
Prism printers that are mounted on autoloaders or AutoPrism AutoPrinters
have different conditions.
Operator Button with
Error Indicator Light
Disc Not Present
Indicator Light
Active Indicator Light
Power Indicator Light
Operator Panel
Image Name Functionality
Error • The Error indicator light on the operator button
indicator illuminates when an error occurs during printing.
light • The Error indicator light and the Disc Not Present
indicator light flash when the printer is in cleaning
mode.
• The Error indicator light illuminates and the Disc Not
Present indicator light flashes at a slow rate when the
ribbon is out.
2001809_A
Indicator
For more information visit rimage.com/support
Name Functionality
Disc Not • The Disc Not Present indicator light flashes a fault code
Present when an error occurs. After the error is resolved, press
indicator the operator button to turn off the indicator light.
light • The Disc Not Present indicator light illuminates when
the tray is empty or when the disc is not properly
clamped. When a disc is placed on the tray, the Disc
Not Present indicator light turns off.
• In Multiple Copy mode, the Disc Not Present indicator
light illuminates until the disc is removed from the
pad.
• The Disc Not Present indicator light flashes
continuously at slow rate when the remaining ribbon
capacity is below 100 discs for monocolor ribbons and
25 discs for CMY ribbons.
• The Disc Not Present indicator light flashes at a slow
rate and the Error indicator light illuminates when the
ribbon is out.
• The Disc Not Present indicator light and the Error
indicator light flash when the printer is in cleaning
mode.
Active • The Active indicator light flashes when the printer is
indicator operating.
light • The Active indicator light flashes continuously at a slow
rate when the printer is in AutoPrinter mode.
Power • The Power indicator light illuminates when the printer
indicator is powered on.
light • The Power indicator light flashes when the system
board has detected a fatal error.
• The Power indicator light turns off when the printer
detects a bad pixel element in the print head. The
Power indicator light turns back on when a disc is
placed on the tray and you can continue to print discs.
If you continue to print, small lines may occur in your
print jobs. This is an indication that the print head may
require replacement.
• The Power indicator light turns off when the printer is
powered off.
