OCEAN W6
Legend
Front plate:
A
Touch-Tronic-Icon
B
Thermostat knob to adjust the
temperature, including a
button for bypassing the
38 °C safety lock.
C Infrared sensor to detect
user interaction with the
fitting (sensor range).
Mounting frame with integrated electronics
A
ON
OFF
1 2 3 4 5 6
B
C
D
G
ON
OFF
1 2 3 4 5 6
Range control
D
E Time control
Interval control
F
DIP switches for configuring
G
the functions
H
I
E F
H
Connection, magnetic valve
I Connection, bypass magnetic
valve f. therm. disinfection
J Connection terminal for
12-V power supply
WimTec OCEAN W6
Wall tap control
EN
J
