6 .2 LED display, flashing codes, clocking diagnosis output

Color Function
Green Safe sensor function
OSSD input circuit available,
On
Door closed
Flashes
Door opened
1 x
Flashes OSSD input circuit not available
2 x Door closed
Flashes OSSD input circuit not available
4 x Door opened
Blue Guard locking function
off Magnet not actuated
on Door closed, locking force available
Flashes Door closed,
1 x Locking force not reached
Flashes
Door opened, magnet actuated
2 x
Fast
Magnet calibration running
flashes
Rot Fault diagnosis
off No error present
on Internal device error
Flashes
Error safety outputs
1 x
Flashes
Error safety inputs
2 x
Flashes
Overvoltage or undervoltage
3 x
Flashes
Error door torn opened
4 x
Flashes Temperature outside the
5 x Permitted range
Flashes
Wrong RFID actuator
6 x
Flashes
Error magnetic flux measurement
7 x
Flashes
configured B10 - value exceeded
8 x
D
Flashes
RFID sync error
9 x
Table 2: LED display, flashing codes, clocking diagnosis output
EN
Diagnosis
Possible cause
output Pin 5
Clock 1
- One door incl. process guard locking opened in the
previous circle
Clock 2
- Wiring error
- Cable interruption
- One door incl. process guard locking opened in the
previous circle
Clock 22
- Wiring error
- Cable interruption
- Unit soiled
- Alignment of the anchor plate not correct
- Incorrect calibration
- Magnet actuated and the door opened
Clock 18 - Internal device error
- Short circuit between safety outputs, against ground
Cycle 11
or against +24 V DC
- Short circuit between safety inputs, against ground
or against +24 V DC
Clock 12
- Only one of the two safety inputs available
- Wire break
Clock 13 - The supply voltage was not applied in the defined area
- Door was forcibly opened when the max. locking
Clock 14
force was exceeded
- The defined temperature range has been undercut
Clock 15
or exceeded
Clock 16 - Incorrect actuator in sensor detection zone
Clock 17 - Magnetic flow measurement does not work
- Value achieved for replacement of connected relay
Clock 20
module (user programmed)
Clock 18
Possible remedy
- Close all doors
- at pin 2 and pin 6 +24 V
- or connect the output signals of the previous process
guard locking
- Close all doors
- at pin 2 and pin 6 +24 V
- or connect the output signals of the previous process
guard locking
- Clean HOLDX and the anchor plate
- Check alignment of HOLDX to the anchor plate
- Recalibrate with HOLDX Manager
- Close the door
- Switch off and apply again the power supply
- Return to supplier in case of recurrence
- Switch off the power supply
- Repair the short-circuit/wire break at the output
- Apply again the supply voltage
- Switch off the power supply
- Repair the short-circuit/wire break at the output
- Apply again the supply voltage
- Switch off the power supply
- Ensure the correct power supply and apply the power
supply again
- Switch off and apply again the power supply
- Switch off the power supply
- Ensure correct ambient temperature
- Apply again the supply voltage
- Use correct actuator
- Exchange
- Exchange
- Check supply voltage
