3 .7 Approach directions

Fig.10: Direction of approach is frontal.
24

3 .8 Switching distance

S
x
Fig.11: S ecorresponds to S , S , S
x ao n ar
ON (S )
ao
TYPE (S )
n
OFF (S )
ar
Terms acc. to EN IEC 60947-5-3:
S = Assured operating distance ON
ao
S = Typical switching distance
n
S = Assured operating distance OFF
ar
Fig.12: Switching distance

3 .9 Limit range monitoring

If the actuator is in the limit range of the switching distances, see Section „2.8 Technical
data", with the corresponding offset values of the sensor, this information is transmitted
to a PLC (output serial-out pin 5) or displayed via the LEDs, see Section „6.2 LED display,
flashing codes, clocking diagnosis output".
HOLDX RL1-P8-S-B-S0129
HOLDX RL1-P8-W-B-S0131
S = 18 mm
ar
S = 11 mm
n
S = 6 mm
ao
