Gate Control PRO – 4G/2G/WiFi Quick Guide

PROGRAMMING SOFTWARE:

The latest version of the programming software is available on the
manufacturer's website.
Connecting via USB
- Launch the Gate Control programming software.
- Power up the device and then connect it to the computer using a
USB-A / USB-B cable.
- Select the USB
- Enter the USB connection password (default password: 1234), and then
click on the Connect
- To configure the settings, reading the settings stored in the device is needed,
which is done automatically after connecting to the device. However, you can
also read the settings manually anytime by clicking on the Read settings
button in any submenu under the Device settings menu group.
- Configure the settings as needed, and then write the changed settings into the
device by clicking on the Write settings
Quick setup wizard:
The quick setup wizard will guide you through the essential settings and helps
you to get the device up and running quickly. The wizard starts automatically
if you connect a device with blank settings (e.g., a new device that has not been
configured yet, or after performing a factory reset). However, you can start
the wizard any time by clicking on the Quick setup wizard
Connection type menu.
APN, PIN code, and Cloud:
The mobile app and remote access work through cloud service. To access the
device remotely over the Internet, the APN must be configured in the
SIM settings section in the General device settings menu, and the Cloud usage
option must be enabled too.
Configure the APN even if you don't want to use the device with an Internet
connection!
If you want to lock the SIM card with a PIN code, enter the PIN code of the SIM
card in the SIM settings section, and enable PIN code request on the SIM card.
In case of using a SIM card that uses a private APN, accessing the cloud server
IP address in the given APN must be specifically enabled at the mobile service
provider. The cloud contact details are the following:
Server address: 54.75.242.103
:
option in the Connection type menu.
button.
button.
Server port: 2016
5
button in the
