ESH Basic-FUBO-GK/MBK - Single-line building package
for buildings without a basement

14 Assembly for Sleeve cap

The fitting of the MS78 sleeve cap takes place at the pipe
15
end of the KES cable entry system or at the end of the
extended pipe system.
The information of the accompanying assembly instruc-
tions "PolySafe sealing elements and sleeve caps"
apply (see Fig.: 25).
To seal the duct ends in the supply trench, we rec-
ommend using the Hauff sleeve caps 2 x MS78-U
and 1 x MS78-KD.
The sleeve cap is usually mounted before the cable/
pipe laying, even if no allocation is immediately
planned.
34
All manuals and user guides at all-guides.com
Art. Nr.: 5090033074 Rev.: 01/2018-09-05
EN
Fig.: 23
