Chapter II
Additional error according to crest factor :
% of
Crest
range
factor
100
1,414
100
2
67
3
50
4
40
5
Intermittent signal sounds and « OL » on the display in case of range overpassing.

5.2.3. DC currents (except MX 23)

Selector switch
Ranges Accuracy
position
500 mA 500 mA 0.3 % R + 2 D
DC DC
50 mA 50 mA 0,3 % R + 2 D
DC (∗∗∗) DC
10 A 1 % R + 5 D
(∗∗)
10 A
DC
DC
(∗) Refer to fuse specifications section 3.4.1.
(∗∗) Acceptance 20 A overload during 30 s. max, observing a 5 min break at least between two
measurements. At 10 A, the measurement is limited to a period of 30 minutes.
(∗∗∗) MX 24
Number of count : 5000
« OL » on the display (range 500 mA
in case of range overpassing.

5.2.4. AC currents (AC+DC) (except MX 23)

Selector switch
Ranges
position 40 Hz to 1 kHz
500 mA 500 mA 1.5 % R + 2 D
AC+DC AC+DC
50 mA 50 mA 1,5 % R + 2 D
AC+DC (***) AC+DC
(∗∗) 10 A 2.5 % R + 5 D
10 A
AC+DC
AC+DC
(∗) Refer to fuse specifications section 3.4.1.
(∗∗) Acceptance 20 A overload during 30 s. max, observing a 5 min break at least between two
measurements. At 10 A, the measurement is limited to a period of 30 minutes.
(∗∗∗) MX 24
Specifications applicable from 5 to 100% of range for a sinusoidal signal in band 40 Hz to 1 kHz.
Number of count : 5000
Additional error according to crest factor :
% of
Crest
range
factor
100
1,414
100
2
67
3
50
4
40
5
« OL » on the display (range 500 mAAC+DC (MX 24 : 50 mA
signal sounds in case of range overpassing.
Portable digital multimeters
Max voltage
Protection
drop
< 800 mV 600 V
RMS
< 800 mV 600 V
RMS
< 700 mV 600 V
RMS
(MX 24 : 50 mA ) only) and intermittent signal sounds
DC
DC
Accuracy Max voltage
Protection
drop
< 800 mV 600 V
RMS
< 800 mV 600 V
RMS
< 700 mV 600 V
RMS
) only) and intermittent
AC+DC
Fuses
Resolution
(∗)
F1 + F2 100 µA
DC
F1 100 µA
DC
F2 10 mA
DC
Fuses
Resolution
(∗)
F1 + F2 100 µA
AC+DC
F1 100 µA
AC+DC
F2 10 mA
AC+DC
27
