Push program Key „Water and Air" (permanently) (ROPULS
chemistry in the bottle is supplied to the fluid flow through. The process is stopped when the
bottle is empty. For larger systems may are several bottles required (note information on the
bottle).
When changing bottles follow the instruction:
– Close pipe system, so that no water flows from the system.
– Push program Key „Water and Air" (permanently) (ROPULS
compressed air supply is stopped.
– Close water supply.
– Unscrew the empty bottle and replace them with new bottle.
Improper use may leak liquid from the bottle. Avoid contact with it. Note event
of accidental contact, read the specific safety instructions.
– Press program key „water and air (permanently)" (ROPULS
– Open water supply.
– Open pipe system.
The chemistry in the bottle is supplied to the fluid flow through. The process is stopped when the
bottle is empty.
Close pipe system.
Press program Key „Water and Air" (permanently) (ROPULS
compressed air supply is stopped.
The reaction time depends on the degree of soiling or according to the regulation for disin-
fecting drinking water lines. The system must be closed for it.
After completion of the chemical cleaning, flush the system mechanically until no chemicals
are left in the system (see „First step - Mechanical cleaning of the system integrate").
Third step - preservation of the system (heating circuit) (Fig. B3):
See steps of chemical cleaning. The preservative remains in the system.
2.2 Cleaning
After completion of dosing the ROCLEAN Injector must be flushed thoroughly with clean water
(safety function). Especially paying attention to the cleaning of the tube (see picture).
To clean the hose (the ROPULS is no longer attached to the cleaning system!) Give water to the
rinsed bottle. Set below the output of the injector (right side of ROPULS) an empty container (for
example a bucket). On the ROPULS ROCLEAN push the program button („Water unfair" per-
manently) turn on and operate the fresh water supply. Catch the out coming water from the in-
jector with a container and dispose it in the drainage (Fig. B4).
Note: Always empty full bottles. Do not use it again!
Bottles are to be separated during transport from the injector!
2.3

Chemicals

Disinfection of drinking water pipes (no. 1500000157):
ROPULS disinfectant is a sterilization aid for drinking water based on hydrogen peroxide. It is
chlorine-free and odorless and suitable for all pipe materials. Safety note.
Note DVGW work sheet W 291
The sterilization aid is suitable for sterilization according to DVGW work sheet W291. If a sterili-
zation according to DVGW work sheet W291 will conducted to ensure that the relevant guide-
lines of the worksheet will be kept. If this means the ROCLEAN Injector is not possible, the steri-
lization done via the injection of ROPULS and external metering (see instructions ROPULS
Chapter 6.4). Safety note.
Cleaning of heating circuits with radiators (no. 1500000200)
ROPULS radiator heating circuits cleaner is a neutral cleaner for the removal of chemical con-
taminants in typical heating circuits with radiators such as scaling and encrustations. It is suita-
ble for all pipe materials. ROPULS cleaners should not be longer than 24 hours in the system.
8 ENGLISH
