1

Safety instructions

1.1

Operating personnel

At the ROCLEAN Injector are only persons allowed who have read and understood these in-
structions. In particular, the special safety precautions must be observed strictly.
• Safety Data Sheets are observed!
• Safety instruction must be observed on bottles ROCLEAN!
2 Installation and operating
The rinsing of heating circuits occurs in three steps:
First step: mechanical cleaning of the system (Fig B1)
Cleaning the system with water - air mixture. The pipes are mechanically clean after the clean-
ing. Efficiency losses caused by contamination are eliminated.
Step Two: Chemical cleaning system (Fig B2)
By the chemical cleaning potential leavings will flushed clean of impurities from the system. The
chemical cleaning slows a new contamination of the system down and is the basis for a subse-
quent preservation.
Step three: preservation of the system (Fig B3)
The chemical forms inside the pipe a protective layer and ensures long-lasting protection of the
system.
2.1

Rinsing of drinking water pipes and heating circuits

ROPULS/ ROPULS eDM instructions must be obeyed!!
First step - Mechanical cleaning of the system (Fig. B1):
Make sure that the lever „rinse / ROCLEAN" is set to „flush".
Follow the instructions in the manual ROPULS/ ROPULS eDM „Rinsing during domestic insula-
tion ".Rinse the system as described there. Finally, turn off the flushing compressor off (pressing
the „On / Off" push button) and turn off the water supply.
Second step Chemical cleaning of the system (Fig. B1):
Preparation:
Mount the ROCLEAN Injector in the flow direction at the water outlet side at the ROPULS.
The GK connector is with ROPULS connected. The adapter for the bottle is straight down
aligned, then tighten the nut at the GK connection.
Connect the compressed air hose to the air-side pressure connection.
They also mount the pressure regulator (solid Setting: 2 bar) in the flow direction at the wa-
ter outlet side at the ROPULS. Check for correct installation (arrow on regulator in the flow
direction)
The ROCLEAN Injector should be used only in conjunction with the pressure
regulator at the ROPULS!
The water connection on the supply side of the Compressor must be installed with a sepa-
rator.
Open the ROCLEAN bottle and install at the ROCLEAN Injector. The bottle without a lid is
screwed into the adapter.
Improper use may leak liquid from the bottle. Avoid contact with it. If accidental
contact happen, read the specific safety instructions.
Turn the lever „rinse / ROCLEAN" in position „ROCLEAN".
Push the „On / Off" program key. The compressor fills the tank pressure automatically.
Open the water supply. Open the pipe system.
