Spezifikationen
extsensor all show
extsensor {port_num} {sen_field} value show
extsensor {port_num} {sen_type} label set
"{name}"
extsensor {port_num} {sen_type} label show
extsensor {port_num} type show
extsensor {port_num} {sen_type} {sen_field}
events set {off=0|on=1}
extsensor {port_num} {sen_type} {sen_field}
events show
extsensor {port_num} {sen_type} {sen_field}
events type set
"{EVT_SYSLOG=0,EVT_SNMP=1,EVT_EMAIL=2
,EVT_SMS=3,EVT_GSMEMAIL=4,EVT_BEEPER
=5,EVT_DISPLAY=6,EVT_CONSOLE=7,EVT_M
QTT=8}"
extsensor {port_num} {sen_type} {sen_field}
events type show
extsensor {port_num} {sen_type} {sen_field}
maxval set {num}
extsensor {port_num} {sen_type} {sen_field}
maxval show
extsensor {port_num} {sen_type} {sen_field}
minval set {num}
extsensor {port_num} {sen_type} {sen_field}
minval show
extsensor {port_num} {sen_type} {sen_field} hyst
set {num}
extsensor {port_num} {sen_type} {sen_field} hyst
show
extsensor {port_num} {sen_type} {sen_field}
publish mode set {NONE=0|INTERVAL=1|
DELTA=2|INTERV_DELTA=3}
extsensor {port_num} {sen_type} {sen_field}
publish mode show
extsensor {port_num} {sen_type} {sen_field}
publish mqtt retain set {OFF=0|ON=1}
extsensor {port_num} {sen_type} {sen_field}
publish mqtt retain show
extsensor {port_num} {sen_type} {sen_field}
publish timer set {num_secs}
extsensor {port_num} {sen_type} {sen_field}
publish timer show
extsensor {port_num} {sen_type} {sen_field}
publish delta set {float}
extsensor {port_num} {sen_type} {sen_field}
publish delta show
extsensor period set {24H=0|12H=1|2H=2|1H=3|
30MIN=4}
extsensor period show
extsensor {port_num} {sen_field} calib set {float}
extsensor {port_num} {sen_field} calib show
http
http server set {HTTP_BOTH=0|HTTPS_ONLY=1|
HTTP_ONLY=22|HTTPS_REDIR=3}
http server show
http port set {ip_port}
http port show
http portssl set {ip_port}
http portssl show
http tls mode set {TLS12=0|TLS13_12=1|
TLS13=2|TLS13_12_11=3}
http tls mode show
http auth mode set {BASIC=0|SESSION=1|
SESSION_EXT=2}
http auth mode show
http passwd enabled set {OFF=0|ON=1}
http timeout admin set {num_secs}
http timeout admin show
http timeout user set {num_secs}
http timeout user show
http passwd enabled show
http passwd local set {OFF=0|ON=1}
http passwd local show
65
Expert Sensor Box 7213/7214
shows all plugged sensors and fields
shows sensor value
sets sensor name to label
shows label of sensor
shows type of sensor
enables sensor events on/off
shows if sensor events are enabled
enables different event types
shows what event types are enabled
sets maximum value for sensor
shows maximum value for sensor
sets minimum value for sensor
shows minimum value for sensor
sets hysterese value for sensor
shows hysterese value for sensor
sets publish mode
shows publish mode
sets mqtt retain
shows if mqtt retain set
sets publish time interval
shows publish time interval
sets publish delta value
shows publish delta value
sets sensor Min/Max measurement period
shows sensor Min/Max measurement period
sets calibration offset for temperature or humidity
shows calibration offset for temperature or
humidity
enters cmd group "http"
sets accepted connection types
shows accepted connection types
sets http port
shows http port
sets https port
shows https port
restricts TLS mode
shows TLS mode restriction
sets http session authentication mode
shows http session authentication mode and
compatibility
enables http password on/off
sets admin session timeout
shows admin session timeout
sets user session timeout
shows user session timeout
shows if http password enabled
enables local login on/off
shows if local login enabled
6
6
6
6
6
6
6
6
6
6
6
6
6
