Tile Laying; Damages Of Suction Plate - probst VPH-100 GREENLINE Betriebsanleitung

Operation
6.7

Tile laying

Recommended device configuration:
•
VPH basic device+
•
VPH-RS wheel set+
•
VPH-RS-AS, height adjustable stop, to put the tile in different angle positions, tilted to the front.
Example for tile laying
6.8

Damages of suction plate

Avoidance of damages:
Otherwise the rubber seal on the suction plate could be damaged (danger of pressure loss).
Product could fall down. Danger of accidents!
To avoid damages of the rubber seal on the suction plate (chinks, abrasion) take notice, that:
•
during the operation (lifting, transporting and lowering) with the device, the suction plate does
not brush or pump against other products or materials.
52710008 / 51720009
Only with the height adjustable stop VPH-RS-AS loads can be sucked in
eccentrically.
Otherwise the load can become detached or break!
19 / 28 GB
