Jacobsen HR-9016 Turbo Wartungsanleitung Und Stückliste Seite 71

Item Part No.
403910
1
2 366670
3 364016
4 400260
5 453011
6 446140
7 443110
8 3009544
9 403860
10 453004
11 446112
12 444306
13 2822524
14 452002
15 446118
16 444310
> 17 3001307
18 REF
19 -
20 -
21 400182
22 446134
23 453009
24 404022
25 453023
26 446128
27 443102
Qty. Description
2 Screw, #10-32 x 1/2" Truss Head
1 Horn
1 Clamp, Wire Harness
1 Screw, 3/8-16 x 7/8" Hex Head
1 Flat Washer, 3/8
1 Lockwasher, 3/8
1 Nut, 3/8-16 Hex
1 Relay, Time Delay
2 Screw, #8-32 x 5/8" Truss Head
2 Flat Washer, #8
2 Lockwasher, #8 Heavy
2 Nut, #8-32 Hex
1 Bracket, Relay
2 Flat Washer, #10
2 Lockwasher, #10
2 Nut, #10-24 Hex
3 Relay, SPDT with Resistor
1 Harness, Kubota Key Switch
1 Control Panel
1 Instrument Panel
3 Screw, 5/16-18 x 5/8" Hex Head
3 Lockwasher, 5/16
3 Flat Washer, 5/16
4 Screw, 1/4-20 x 1" Truss Head
4 Flat Washer, 1/4
4 Lockwasher, 1/4
4 Nut, 1/4-20 Hex
Serial Numbers/Notes
REFERENCE U11, See 68.1
REFERENCE U2, See 68.1
REFERENCE K15, K16, K17, See 68.1
See 45.1
See 7.1 and 8.1
See 5.1
> Change from previous revision
HR-9016
41
