Jacobsen HR-9016 Turbo Wartungsanleitung Und Stückliste Seite 103

Item Part No. Qty.
–
1
2 4136298
3 3008821
4
5 4136286
6 4136285
7 4132013
8 365979
9 446154
10 4134448
11 400266
12 446142
13 443110
14 4137616
15 4136227
16 323943
17 400264
18 400422
19 452012
20 446166
21 443118
22 361071
23 4136245
24 444762
25 443128
26 363996
27 446154
28 400656
29 452016
Description
1 Engine and Pump Assembly
1 Fan
1 Temperature Sender
1 Engine Mount, Right Hand
1 Engine Mount, Left Hand
2 Engine Mount, Rear
19 Screw, M12-1.25 x 25mm Hex Head
19 Lockwasher, 1/2 Heavy
1 Drive Shaft
2 Screw, 3/8-16 x 1-1/2" Hex Head
8 Lockwasher, 3/8 Heavy
8 Nut, 3/8-16 Hex
2 Isolator, Rear
2 Isolator, Front
2 Washer, 2"O.D. x 17/32" I.D.
8 Screw, 3/8-16 x 1-1/4" Hex Head
2 Screw, 1/2-13 x 4" Hex Head
2 Flat Washer, 1/2
2 Lockwasher, 5/8" Heavy
2 Nut, 1/2-13 Hex
2 Flat Washer, Isolator
4 Screw, M8-1.25 x 50mm Hex Flange
2 Locknut, 3/8-16 Center
2 Nut, 5/8-18 Hex
1 Switch, Temperature Warning
2 Lockwasher, 1/2" Heavy
2 Screw, 5/8-18 x 4" Hex Head
2 Flat Washer, 5/8
Serial Numbers/Notes
See 22.1
Mounting Hardware Part of Engine
REFERENCE U6, See 68.1
REFERENCE SW17, See 68.1
> Change from previous revision
HR-9016
73
