MOUNTING THE RF REMOTE CONTROL
On the wall
x2
Unscrew the 2 screws
under the RF remote control.
BINDING THE RF RECEIVER WITH THE RF REMOTE CONTROL
The RF remote control and the RF receiver are not paired at the factory.
Attention: A maximum of 5 RF receivers can be connected to 1 RF remote control
Proceed as follows and do this for each RF receiver:
RF pairing:
1. Put the RF receiver in pairing mode by pressing the
The
LED will start to blink in RED.
2. Put the RF remote control in frost protection mode by pressing
the
button 3x and press
3. To ensure correct operation of the radiator, the power of the radiator must be adjusted
via the RF remote control. This step is automatically covered during pairing.
The power is set to 500W as standard.
Use the
and
keys to set the power (see rating plate radiator).
4. When the RF remote control and the RF receiver are linked, the
and is constantly displayed.
RF pairing cancellation:
Press more than 10 seconds on Memo button of the RF receiver.
Operating status
Operating status
Standby
Power on
Heating on
Boost
Frost protection mode, open
window detection
Manual override (MEMO-button)
04
Secure the wall plate with the
two screws provided using the
horizontal and vertical holes.
for 5 sec.
LED status and colour
Off
Green
Red
Blinking red
Blinking green
Blinking orange
On the table stand
Insert the 2 pins
inside the wall plate.
button for 5 sec.
5 s
symbol appears
RF communication status
RF communication status
Standby
No RF connection
RF pairing mode
RF pairing cancellation
RF connection OK
RF message received
Slide the stand
to the right.
5 sec.
10 s
LED status and colour
Off
Red
Blinking red
Fast blinking red
Green
1 sec fast blinking green
