This appliance complies with the European directive 'ECO Design Directive 2015/1188':
Information requirements for electrical appliances for local space heating
Parameter
Nominal heat output
Minimal heat output
Maximal continuous heat output
At nominal heat output
At minimal heat output
In stand-by mode
Type of heat output/control of room temperature
Electronic control of the room temperature plus a week-time switch
Control of room temperature, including automatic detection of open windows
With optional remote control, if applicable for this appliance (see catalog)
RF
With adaptive start control
See ID plate on the radiator

MOUNTING THE CONTROLLER

INSTALLING BATTERIES

Remove the battery cover which is placed
on the front of the RF remote control.
Symbol
Heat output
P nom
P min
P max,c
Additional electricity consumption
el max
el min
el sb
Other control options
Contact details
Screw the controller with
the included allen key.
Insert the 2 AA batteries supplied. Note the correct
polarity according to the engraving on the
RF remote control when inserting the batteries.
Value Unit
0,5 → 1,5
kW
0,5 kW
1,5 kW
0,000 kW
0,000 kW
0,0005 kW
Screw the controller with
the included allen key.
Replace the battery cover.
