3. Push down on the dust bin fastener. The container lid will open and you can empty
the container.
4. Close the lid of the dust bin. The fastener must lock into place. Help closing the lid if
necessary by pushing the fastener up against the dust bin lid.
C
D
Cleaning the motor fi lter
Cleaning the exhaust fi lter
1. Open the exhaust fl ap on the back of the vacuum cleaner. The exhaust fi lter is
located behind the exhaust fl ap.
2. Remove the exhaust fi lter.
3. Shake out the fi lter over an open garbage can.
5. Depress and hold the release button and put the dust bin
back in the vacuum cleaner. The dust bin has been prop-
erly positioned when the release button pin (C) is located
under the bracket (D) on the vacuum cleaner housing (see
fi gure).
1. Remove the dust bin (see section "Emptying the dust bin").
1
The motor fi lter (1) is located behind the dust bin in the
vacuum cleaner housing. It is protected by a foam fi lter.
2. Remove the foam fi lter.
3. Turn the frame with the fi lter counterclockwise and re-
move it. Reach into the two recesses on the frame in
order to rotate and remove the frame.
4. Shake out the fi lter over an open garbage can.
5. If needed, clean the fi lter with clear, lukewarm water and
allow it to dry completely. Do not insert the fi lter if it is still
moist.
6. Place the frame with the fi lter back in the vacuum cleaner
housing and turn it clockwise to secure it. Reach into the
two recesses on the frame as when removing it.
7. The motor fi lter is in place when the frame is fl ush with
D
the vacuum cleaner housing and the recesses on the
frame are perpendicular to the bracket (D) on the vacuum
cleaner housing and are vertically in line with one another
(see fi gure).
