Multiple Port Shower Sump
Security
• The shower sump may not be used for other liquid than water/bilge water.
• Always install the pump with black lead (-) and brown/white lead (+).
• Always use the fuse required, see "Design features" below.
• The wire connections must be sealed with a marine sealant.
• All electrical wiring must be clamped with the connections well above the bilge
water level. Do not remove the insulation more than necessary. All wiring
connections should be sealed with a marine sealant to avoid oxidation.
• Do not run dry.
Type designation
Multi Port Shower Sump
Multi Port Shower Sump
Features
Capacity, straight (13.6V/27.2V)
61 l/min - 972 GPH
Capacity 0.9 m head (13.6V/27.2V)
53 l/min - 844 GPH
Container:
Lid:
Check valve
Voltage:
Amperage:
Fuse size:

Mounting instructions

Fasten the shower sump to the hull by screws in the two mounting holes.
Operation
See illustration page 15.
1. When the bilge water rises and reaches the second detector cell at 50 mm (2")
the switch starts the pump, with a 3 second delay.
2. When the water level has sunk to a level of 20 mm (¾"), and the first detector
cell is above the water level, the pump is stopped.
Original instructions
12V
24V
Thermoplastic,
white
Acrylic, clear
Flapper valve, nitrile
12V 24V DC
3.2A 2A
5A 3A
Part No. Part No. US
32-57151-01 57151
32-57151-02 57151-24
Intake hose:
Discharge hose:
Dimensions:
With connections:
Without connections: 8.3" x 8.3" x 5.5"
Weight:
> English
1x¾"
1x¾" or 1x1"
1x1⅛" or 1x1½"
¾"
11.4" x 8.3" x 5.5"
(290 x 211 x 140mm)
(211 x 211 x 140mm)
2.3 lbs (1.04 kg)
