1. Description

The EX-6112-2PoE is a multi-protocol RS-232 serial Device Server designed to connect RS-232
serial devices, including point-of-sale systems, barcode readers, sensors, meters, weighing
systems, CNC controllers and PLCs, to an IP-based Ethernet network. The serial devices are
connected via Ethernet and are available for sharing on the subnet and Internet. Remote
configuration is done via extensive network protocols such as TCP server, TCP client, UDP,
VCOM or serial Telnet/RFC2217. To ensure backward compatibility with legacy serial devices
running existing COM port application software, the EX-6112-2PoE provides a virtual COM port
(VCOM) that perfectly migrates your serial application without modifying the software. The EX-
6112-2PoE supports Power over Ethernet and can be powered directly from a PoE-compliant
power supply unit (PSE) via the Ethernet cable. In addition, serial devices can communicate with
each other in peer-to-peer mode without the need for an intermediate PC or conversion software.
Features:
•
2x RS-232 DB9 serial port over RJ45 Ethernet 10/100Mbps
•
Serial Ports: RS-232 V24
•
Network Protocols: TCP Server, TCP Client, UDP, VCOM, Serial Telnet/RFC2217
•
Configuration: Windows-based SDS Administrator Utility and Web-Browser
•
15KV ESD-Protection for all serial Signals
•
Supports 5V over serial Connector
•
IEEE802.3af PoE-PD: Can be powered by Ethernet cable
•
Certificates

2. Extent of delivery

Before you integrate the EX-6112-2PoE into your network, you should first check the contents of
the delivery:
•
EX-6112-2PoE
•
Power Supply (12V/3A)
•
Manual
