Airpurge is active
Voltage or
overtemperature
error
Overcurrent error
Start error
Position sensing
error
Offset error
Beyond the basic signal functions, ecocirc PREMIUM configuration is
equipped with a digital display as well. The display provides
information on the actual hydraulic performance and electrical power of
the pump on the following way: The display shows the electrical power
of the pump in Watts for 10 seconds, than shows the elevated water
column height (differential pressure) in meters for 10 seconds, than the
actual flow in m3/h for 10 seconds. Than the display returns to the
energy consumption in Watts and the cycle starts again.
The PREMIUM display messages also provide detailed information on
the air purge mode status as well as detailed error messages:
DISPLAY
oFF
Lo
xx.x W
x.x m
x.xx m3/h
0.75 s off / 0.1 s on
mode dependent color
1s on/1s off, mode dependent
color.
0.2 s on / 0.2 s off, mode
dependent color.
0.4 s off / 0.1 s on / 0.4 s off / 0.4 s
on, mode dependent color
DESCRIPTION
Pump is in standby state.
Pump runs, but the flow in the
system is too low to measure it
precisely
The display shows pump power
consumption.
The display shows pump head
Pump flow rate.
Note: flow rate is not displayed
below 300 litre/h. See Lo.
22
-
Check the mains voltage
Let the pump cool and
restart
Check for foreign object
blocking the pump rotor (
Section 8)
Electronics board defect,
non-serviceable
DEF
-
-
-
-
-
