Series
ecocirc...-4
ecocirc...-6
For connection diameters see figure 1
ATTENTION
with power range up to approx. 50 kW (radiator heating systems up to
approx. 500 m² living space, underfloor heating systems up to approx.
200 m² floor space). The power of the ecocirc
adjusted by applying phase trimming ("pulsing") to the supply voltage.
3. Dimensions (see figure 1)
4. Technical Specifications
Rated voltage
Frequency
Power consumption
Energy Efficiency Index
(EEI)*
IP protection
Insulation class
Protection class
Max. system pressure
Permitted temperature
range of pumped fluid**
Permitted pumping
media***
* The benchmark for the most efficient circulators is EEI ≤ 0.20
** Must not freeze. To avoid condensation the fluid temperature
must always be higher than the ambient temperature.
*** Performance of the pump will noticeably change when pumping
water/glycol mixtures with concentrations higher than 20%.
5. Characteristic Curves (see figure 2a + 2b +2c)
6. Installation Advice
Max. delivery height
3.5 m
5.7 m

The ecocirc pumps are suitable for heating systems
"ecocirc...-4"
200-240 V
50/60 Hz
4-23 W
see label on the
front page
IP 44
Class 155 (F)
I
10 bar
-10 °C to +110 °C
Heating water according to VDI 2035,
water/glycol mixtures
Max. delivery volume
2500 l/h
3200 l/h

pump must not be
18
"ecocirc...-6"
200-240 V
50/60 Hz
4-42 W
see label on the
front page
IP 44
Class 155 (F)
I
10 bar
-10 °C to +110 °C
