IC-KP2-2HB18-2V1
Befehle

Schreibbefehl single mit geteilten Daten

ID command execution request (RYn4)
Abbildung 7.10

Schreibbefehl enhanced ohne geteilte Daten

ID command execution request (RYn4)
Abbildung 7.11
42
writing cmd and data
part 1 to RWw
PLC program
ID BUSY (RXn3)
ID division data request (RXn7)
ID division data complete (RYn7)
ID command complete (RXn4)
ID data ack (RYn3)
ID in zone contact (RXn2)
Tag communication
ID error occurrence (RXn5)
writing cmd and data
PLC program
ID BUSY (RXn3)
ID division data request (RXn7)
ID division data complete (RYn7)
ID command complete (RXn4)
ID data ack (RYn3)
ID in zone contact (RXn2)
Tag communication
ID error occurrence (RXn5)
writing data
part 2 to RWw
reading response
to RWw from RWr
reading response
from RWr
reading response
from RWr
