Reflex Exvoid Betriebsanleitung Seite 222

Extwin
Ø1
(mm)
TW 60.3 4,0 60,3
TW 76.1 5,0 76,1
TW 88.9 12,0 88,9
TW 114.3 14,0 114,3
TW 139.7 34,0 139,7
TW 168.3 31,0 168,3
TW 219.1 113,0 219,1
TW 273.0 215,0 273,0
TW 323.9 265,0 323,9
Ø1
TW 50 10,0 DN50/PN16
TW 65 10,0 DN65/PN16
TW 80 18,0 DN80/PN16
TW 100 24,0 DN100/PN16
TW 125 41,0 DN125/PN16
TW 150 46,0 DN150/PN16
TW 200 79,0 DN200/PN16
TW 250 156,0 DN250/PN16
TW 300 325,0 DN300/PN16
TW 350 - DN350/PN16
TW 400 - DN400/PN16
TW 450 - DN450/PN16
TW 500 - DN500/PN16
TW 600 - DN600/PN16
Ø1
(mm)
TW 60.3 R 13,0 60,3
TW 76.1 R 13,0 76,1
TW 88.9 R 46,0 88,9
TW 114.3 R 36,0 114,3
TW 139.7 R 102,0 139,7
TW 168.3 R 78,0 168,3
TW 219.1 R 182,0 219,1
TW 273.0 R 180,0 273,0
TW 323.9 R 450,0 323,9
Ø1
TW 50 R 18,0 DN50/PN16
TW 65 R 19,0 DN65/PN16
TW 80 R 43,0 DN80/PN16
TW 100 R 51,0 DN100/PN16
TW 125 R 89,0 DN125/PN16
TW 150 R 94,0 DN150/PN16
TW 200 R 138,0 DN200/PN16
TW 250 R 355,0 DN250/PN16
TW 300 R 500,0 DN300/PN16
TW 350 R - DN350/PN16
TW 400 R - DN400/PN16
TW 450 R - DN450/PN16
TW 500 R - DN500/PN16
TW 600 R - DN600/PN16
L Ø
(m /h) (mm) (mm)
3
12,5 260 132
20 260 132
27 370 206
47 370 206
72 525 354
108 525 354
180 650 409
288 750 480
405 850 634
L Ø2
(m /h) (mm) (mm)
3
12,5 350 132
20 350 132
27 470 206
47 470 206
72 635 354
108 635 354
180 775 409
288 890 480
405 1005 634
500 1128 650
650 1226 750
850 1330 750
1060 1430 1000
1530 1630 1200
L Ø2
(m /h) (mm) (mm)
3
12,5 260 132
20 260 132
27 370 206
47 370 206
72 525 354
108 525 354
180 650 409
288 750 480
405 850 634
L Ø2
(m /h) (mm) (mm)
3
12,5 350 132
20 350 132
27 470 206
47 470 206
72 635 354
108 635 354
180 775 409
288 890 480
405 1005 634
500 1128 650
650 1226 750
850 1330 1000
1060 1430 3500
1530 1630 4100
H HM1 HM2
(mm) (mm) (mm)
785 335 450
785 335 450
940 413 527
940 413 527
1200 542 658
1200 542 658
1470 678 792
1916 915 1001
2237 1076 1161
H HM1 HM2
(mm) (mm) (mm)
785 335 450
785 335 450
940 413 527
940 413 527
1200 542 658
1200 542 658
1470 678 792
1916 915 1001
2237 1076 1161
2600 1257 1343
2900 1407 1493
3150 1532 1618
3500 1707 1793
4100 2007 2093
H HM1 HM2
(mm) (mm) (mm)
785 335 450
785 335 450
940 413 527
940 413 527
1200 542 658
1200 542 658
1470 678 792
1916 915 1001
2237 1076 1161
H HM1 HM2
(mm) (mm) (mm)
785 335 450
785 335 450
940 413 527
940 413 527
1200 542 658
1200 542 658
1470 678 792
1916 915 1001
2237 1076 1161
2600 1257 1343
2900 1407 1493
3150 1532 1618
3500 1707 1793
4100 2007 2093
