Setting up the awning tent
A
NOTICE! Material damage
Do not open or close the zippers by force.
I
NOTE
•
The awning tent comes with general purpose pegs.
These will be suitable for many sites but for some types
of ground special pegs will be needed. Ask your dealer.
•
Drive the pegs at a 45° angle away from the awning tent
into the ground.
•
Peg each guy line in-line with the seam it starts from.
Keep the following tips in mind while setting up the awning tent:
•
The figures provide a general overview of the set-up. The actual set-up
will vary slightly based on the model of awning tent.
•
Get help. The set-up is easier with more people.
•
Push the poles into the sleeves from front to rear.
•
After standing the awning tent upright, check the corner pegs and re-
peg if necessary. The groundsheet on the inside should be taut and in
a rectangular shape.
•
Peg the guy lines so that the awning tent is under tension without dis-
torting the shape.
•
If available, attach the storm straps.
•
Check the guy lines from time to time to ensure adequate tension, if
necessary use the runners to adjust.
Set up the awning tent as follows:
1. To protect the awning tent from dirt and damage, lay down a ground-
sheet or footprint before unpacking.
2. Unpack the awning tent.
3. Separate and identify the different components.
4. Proceed as shown to set up the awning tent (fig. 1, page 3 to
fig. n, page 6).
Dismantling the awning tent
A
NOTICE! Material damage
Do not use force when dismantling the awning tent. Other-
wise you might damage any material.
1. Reverse the set up procedure.
2. Push the poles out of the sleeves, do not pull.
3. Ensure that all parts are clean before packing in the carry bag.
4. If the awning tent is wet or damp, dry fully as soon as possible.
Cleaning and maintenance
A
NOTICE! Damage hazard
•
Do not use sharp or hard objects or cleaning agents for
cleaning.
•
Do not use alcohol based materials, chemicals, soap
and detergents for cleaning.
•
Remove bird droppings and tree resin as soon as
possible to avoid permanent damage to the material.
1. If necessary, clean the product with clean water and a soft brush.
2. Apply impregnation against water and UV radiation before each trip.
8
Storing the awning tent
I
NOTE
•
Fully set up the awning tent for cleaning.
•
Choose a sunny day for cleaning to ensure the material
will dry thoroughly.
1. Clean the awning tent.
2. Air fully and ensure the awning tent is totally dry before packing away.
3. Store in a well ventilated dry place.
Troubleshooting
I
NOTE
•
During first exposure to water there may be some
moisture at the seams. Through this moisture the threads
will swell and fill the holes that are created in the sewing
process.
•
A fully equipped spare parts kit should include:
–
–
–
–
Problem
Water leak
Rip in the fabric
Pole has broken
Rear of awning tent is too
far or too close to motor-
home or caravan
Awning tent is sagging in
the roof
Awning tent is moving in
the rail
Connecting spring has
broken
Condensation
All awning tents suffer from internal condensation if one or more of the
following conditions apply:
•
high air humidity
•
high ground moisture
•
a drop in temperature
Severe condensation can run down the inside of the roof and drip off ties,
tapes and other internal fittings and can be mistaken for leaking.
➤ Increase ventilation by opening doors and/or windows.
➤ Install a waterproof groundsheet.
4445103458
Waterproofer
Repair tape and repair solution
Silicone spray for the zippers
Spare pegs
Solution
➤ Check for leaky seams, damaged tapings and
moist areas.
➤ If you cannot find any leaks, see chapter "Con-
densation" on page 8.
➤ If you find any leaks, apply seam sealant.
➤ Use repair tape to seal the fabric.
➤ Have repairs carried out by an authorized spe-
cialist.
➤ Use a metal peg as a splint by taping it to the
broken pole.
➤ Purchase a new pole.
➤ First peg the rear pegging points before apply-
ing too much tension to the front poles.
➤ Adjust the front poles.
➤ Re-peg the awning tent ensuring roof and walls
are taut.
➤ Use special Monsoon poles (optional acces-
sory).
➤ Re-peg the awning tent ensuring roof and walls
are taut.
➤ Use special rail stoppers (optional accessory).
➤ These parts are wear parts used to install the
poles. If these springs become overstretched
or break, they can be replaced.
EN
