Anhang A ModBUS Register
Tag Name Group Name
TURBIDITY FNU Measurement
TURBIDITY NTU Measurement
TURBIDITY TEF Measurement
TURBIDITY FTU Measurement
TURBIDITY EBC Measurement
SOLID mg/L Measurement
SOLID ppm Measurement
SOLID g/L Measurement
SOLID % Measurement
Reserved Reserved
SET PARAMETER Configuration
UnitTM Unit
UnitDS Unit
OFFSET Calibration
Factor TRB Calibration
Factor TS Calibration
Reserved Reserved
RESPONSE TIME Configuration
LOGGER INTERVAL Configuration
Outputmodekal Service
Outputmodesrv Service
EDITED NAME Configuration
SERIAL NUMBER Configuration
CAL. DATE Configuration
TURBIDITY Calibration
SOLID Calibration
PROGRAM Maintenance
BOOTPROGR. Maintenance
STRUCTURE Maintenance
FIRMWARE Maintenance
CONTENT Maintenance
FormatMinFNU Configuration
FormatMaxFNU Configuration
FormatMinEBC Configuration
FormatMaxEBC Configuration
FormatMinGL Configuration
FormatMaxGL Configuration
FormatMinMGL Configuration
FormatMaxMGL Configuration
FormatMinPR Configuration
Tabelle 3 Sensor ModBUS Registers
Register Data Type
40001 Float
40001 Float
40001 Float
40001 Float
40003 Float
40005 Float
40005 Float
40007 Float
40009 Float
40011 Unsigned Integer
40012 Unsigned Integer
40013 Unsigned Integer
40014 Unsigned Integer
40015 Float
40017 Float
40019 Float
40021 Unsigned Integer
40022 Unsigned Integer
40024 Unsigned Integer
40025 Unsigned Integer
40026 Unsigned Integer
40027 String
40036 String
40042 Time2
40044 Float
40046 Float
40048 Float
40050 Float
40052 Unsigned Integer
40053 Unsigned Integer
40054 Unsigned Integer
40055 Float
40057 Float
40059 Float
40061 Float
40063 Float
40065 Float
40067 Float
40069 Float
40071 Float
Length R/W Description
2 R Trübung in FNU
2 R Trübung in NTU
2 R Trübung in TEF
2 R Trübung in FTU
2 R Trübung in EBC
2 R Feststoff in mg/L
2 R Feststoff in ppm
2 R Feststoff in g/L
2 R Feststoff in Prozent
1 R Reserviert
1 R/W Parameter
1 R/W Einheit Trübung
1 R/W Einheit Feststoff
2 R/W Trübung Offset
2 R/W Trübung Faktor
2 R/W Feststoff Faktor
1 R reserviert
1 R/W Ansprechzeit
1 R/W Loggerintervall
1 R/W Ausgangsmodus Kalibrieren
1 R/W Ausgangsmodus Service
8 R/W Messort
6 R/W Seriennummer
2 R Datum Werkskalibrierung
2 R Sensor Nesswert Trübung
2 R Sensor Nesswert Feststoff
2 R Version Application
2 R Version Bootloader
1 R Version Struktur Treiber
1 R Version Register Treiber
1 R Version Firmware Treiber
unterer Grenzwert Trübung
2 R
in FNU
oberer Grenzwert Trübung
2 R
in FNU
unterer Grenzwert Trübung
2 R
in EBC
2 R oberer Grenzwert Trübung in EBC
2 R unterer Grenzwert Feststoff in g/L
2 R oberer Grenzwert Feststoff in g/L
2 R unterer Grenzwert Feststoff in mg/L
2 R oberer Grenzwert Feststoff in mg/L
unterer Grenzwert Feststoff
2 R
in Prozent
