SENSORS
Name Functional Description
With Laser Ranging-measuring the distance between DEEBOT and surroundings through the time difference of reflection, it can map
Solid-state LiDAR
according to the objects around while DEEBOT is moving. Detection of 10m.
Vibrating the diaphragm through air by human voice, it can realize Vioce Recording and ask DEEBOT to complete the assigned work
Microphone
by Voice Control. Effective wake of 5m.
The sensor emits infrared rays and receives the light reflected from obstacles in front of it. With Infrared Ranging-measuring the
TrueDetect 3D Sensor distance between DEEBOT and surroundings through the time difference of reflection, it can identify and avoid the obstacles nearby.
The measurement range is 0.8m.
With AI Camera's surrounding image collection, it can realize the video recording and meanwhile assist in drawing the 3D map.
AIVI Camera
Through the interaction with the MIC, it can realize the Remote Voice Call. FOV: Vertical 112°, Horizontal 138°.
With Infrared Ranging-detecting the distance between the bottom of DEEBOT and ground by Infrared Sensor at the bottom, DEEBOT
Anti-drop Sensor will not move formard when there are stairs in front (For example: White ground height greater than 55mm. Black ground height
greater than 30mm.) or the identified distance exceeds the present one, realizing the Anti-drop.
The ultrasound probe can emit ultrasonic waves with a frequency of 300KHZ. The energy of the ultrasonic waves is absorbed by the
Carpet Detection Sensor
carpet. If the reflected energy is below the threshold, the DEEBOT recognizes the presence of the carpet.
When the transmitted signal is blocked by an obstacle, the signal receiver will not be able to receive the signal. With this principle,
Anti-collision Sensor
DEEBOT will avoid obstacles when colliding with them.
With ToF distance measurement, DEEBOT can detect the distance between itself and objects on its right side. When there is a wall or
Edge Sensor
obstacle on the right side, DEEBOT will perform edge cleaning to avoid missing spots or collisions.
13 EN
