TECHNICAL DATA

- Liquid/solid protection rating: Sensor: IP69K - Control unit: IP66
- Detection tolerance +/- 30 cm
- Operating temperature: -20 to +70°C
- Detection range: 0.1 to 20 metres
- Up to 5 detection zones
- Detects moving objects: vehicles, motorcycles, bicycles, pedestrians, etc.
- Detects objects even when visibility is limited: during darkness and in smoke, fog and dust
- Configure and update via an app
- Power supply: 10 to 32V DC
The issues described below do not necessarily mean a system fault. Please check the following elements
before submitting a request for repairs:
Issues
No system response when the vehicle
is put into reverse gear
No reaction on the monitor when there
are obstacles in the detection zone
No audible alert when obstacles are
present in the detection zone
The monitor displays the message
"Aucun capteur détecté" (No sensor
detected)
There are no obstacles in the detection
zone, but a constant alert is sounded
UART configuration not possible with
a USB cable
Cannot find a Wi-Fi peripheral on the
PC's configuration tool
Cannot find a Wi-Fi device on the
mobile phone configuration tool
The Wi-Fi connection automatically
disconnects
AMS Diffusion - Rue des Galeries - ZA du Chevalement - 59286 Roost Warendin - FRANCE - Tél. +33 (0)3.27.94.44.44 - Fax. +33 (0)3 27 94 44 45
Email : contact@ams-diffusion.fr - www.ams-diffusion.com RCS DOUAI A 451 360 382 - CODE APE 4531Z - SIRET 451 360 382 00035 - TVA FR 55 451 360 382
4. TECHNICAL ADVICE
Possible causes
No supply input or trigger input
Poor sensor or monitor connection
etc.
The monitor sound is disabled or
set too low
Poor sensor connection
The radar is detecting the ground
There is no power supply to the
control unit or the trigger line input
is high
The Wi-Fi signal is weak or the
computer's Wi-Fi connection is not
working properly
The Wi-Fi signal is weak or your
phone does not have Wi-Fi enabled
Wi-Fi can suffer from interference
Solutions
Check that the power supply input
cable and activation cable are properly
connected
Check that the connections are secure
Enable or turn up the monitor sound
Check that the connections are secure
Adjust the sensor angle
Ensure there is a power supply to the
control unit and that the trigger line input
is low (or no connection)
Bring the computer closer to the radar
control unit and reconnect the Wi-Fi
Check that Wi-Fi is enabled on the
phone and reconnect the Wi-Fi on the
configuration tool
Remove high-frequency interference
sources and restart the control unit
