4.4 I Replacing the brush
• The brush is equipped with wear indicators; the distance between the indicators and the end of the brush indicates
whether the brush is in good condition (see figure
• The brush is worn and should be replaced when the wear indicators appear as shown in figure
• To remove the worn brush, remove the tabs from the holes in which they are fixed (see figure
• To fit the new brush, start by fitting the side without tabs under the brush holder (see figure
• Roll the brush around its support, slide the tabs into the attachment holes and pull on the end of each tab until its
edge passes through the slit (see figure
• Cut the tabs using a pair of scissors for them to be below flap level (see figure
).
).
.
).
).
).
