13 Technical drawings

The indicated measurements are expressed in millimetres.
230
USABLE AREA
A - A
466
B
B
70
422
Fig. 17 VERSO Hi-PoE IPM.
70
USABLE
AREA
B - B
156
171
40 73
156
A
A
