43
Align the holes on the Keyboard Plate with the through holes on the Keyboard Angle Bracket.
44
Bolt through and secure with 2 x M8 Bolts, Washers and Flange Nuts.

KEYBOARD PLATE ADJUSTMENT

A)
45
A) Loosen the Bolts securing the Keyboard Angle Bracket to the Mouse Plate.
B) Adjust to the desired position and tighten the bolts to lock in place.
B)
26
PARTS:
• • 1 x Keyboard Plate
PARTS:
• • 2 x M8 55mm Sockethead Bolts
• • 2 x M8 Flange Nuts
• • 2 x M8 Washers
PARTS:
• • NIL
