Lighting effects must not be connected to dimming-packs.
There is a power output connector and a power input plug on the rear panel. Connect one output with the
input of the next fixture until all fixtures are connected.
Please note:
A maximum of 8 LED Pixel Panels may be linked together. After every 8 LED Pixel Panels,
the fixtures must have a renewed connection with the power mains.
OPERATION
The device has two operating modes. It can be operated via DIP switches in Stand Alone mode or it can be
run via a DMX controller in DMX-controlled mode.
After you connected the LED Panel to the mains, it starts running.
OPERATION VIA DIP SWITCHES
Function:
Color change and Color fade
Program Selection via Dip1 - Dip4
Speed via Dip5 - Dip8
Sound controlled color change
Sensitivity via Dip1 - Dip4
See DMX Protocol
1 = on
0 = off
Slave device in M/S Mode
X = na
Auto Mode
In order to select Color change and Color fade, set all DIP switches to OFF.
The built-in programs run one after the other in a continuous loop with constant speed.
Internal Programs Mode
In order to select from the 15 Internal Programs, set DIP switch 9 and 10 to OFF.
Programs can be selected via DIP switches 1-4 (see following table).
Speed can be adjusted via DIP switches 5 - 8.
Sound Control
In order to select Sound controlled color change, set DIP Switch 9 to ON and DIP Switches 5 - 8 and 10 to
OFF.
Sensitivity can be adjusted via DIP switches 1 - 4.
Dip
Dip
Dip
Dip
Dip
1
2
3
4
5
0
0
0
0
0
X
X
X
X
X
X
X
X
X
0
X
X
X
X
X
0
0
0
0
0
18/22
Dip
Dip
Dip
Dip
Dip
9
10
6
7
8
0
0
0
0
0
X
X
X
1
0
0
0
X
X
X
X
0
0
0
0
00066936.DOC, Version 1.0
Mode:
Auto
0
15 Internal
0
Programs
Sound-
0
control
DMX
1
Slave
1
Mode
