Model assembly

Vertical tail and horizontal tail installation
1.Install the vertical tail to the rear slot of the fuselage, as
shown in the figure.
2. Secure the vertical tail with the attached screws.
3. With the bottom of the fuselage facing up as shown in
the figure, install the fixed shafts to the slots on both
sides of the rear of the fuselage, then secure with the
attached screws.
HKM3.0*16mm
4
HKM3.0*10mm
