General information:

The key-operated button type ST 100 AP is designed for the manual triggering of
garage doors or yard gates. For harmonization the cylinder can be replaced with the one
used in your home's security lock system.

Assembly and connection:

Choose the point of installation.
Screw open the ST 100 AP and remove the cover.
Insert the key in the cylinder.
Turn the key a little to the left or right and pull out the cylinder together with the
cylinder holder.
Insert the stripped end of the cable (min. 2 x 0.65 mm
Screw the case bottom in position.
Take out the button holder together with the button.
Insert one wire into each of the terminals (between the green pins) and screw tight.
Reinsert the button holder with button in the case bottom. To do so, the cylinder must
be turned to between 10 and 11 o'clock!
Plug the cylinder holder with cylinder back in place.
N.B.!
Make sure that the cylinder lug actuates the green pin of the
button when the key-operated button is operated!
Mount the cover.
Lay the cable to the controller of your garage door or yard gate opener and connect
as described in the opener's instructions, e.g. to the button terminals.
N.B.:
When using the ST 100 AP for garage door or yard gate openers, never
connect an external supply (e.g. no 230 V) to the ST 100 AP!
