1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
we hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified,
• A breakdown of the electrical system that occurs
due to the non-compliance of the electric regu-
lations and VDE regulations 0100, DIN 57113 /
VDE0113.
We recommend:
Read through the complete text in the operating in-
structions before installing and commissioning the
device.
The operating instructions are intended to help the
user to become familiar with the machine and take
advantage of its application possibilities in accord-
ance with the recommendations.
The operating instructions contain important informa-
tion on how to operate the machine safely, profes-
sionally and economically, how to avoid danger, cost-
ly repairs, reduce downtimes and how to increase
reliability and service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regu-
lations that apply for the operation of the machine in
your country. Keep the operating instructions pack-
age with the machine at all times and store it in a
plastic cover to protect it from dirt and moisture. Read
the instruction manual each time before operating the
machine and carefully follow its information.
The machine can only be operated by persons who
were instructed concerning the operation of the ma-
chine and who are informed about the associated
dangers. The minimum age requirement must be
complied with.
18 | GB
 www.scheppach.com /  service@scheppach.com /  +800 4002 4002
In addition to the safety notices contained in this
operating manual and the particular instructions for
your country, the generally recognised technical reg-
ulations for the operation of identical devices must be
complied with.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.

2. Device description (Fig. A)

1. Loading slot
2. Machine body
3. Hook
4. Wheel
5. Wheel cap
6. Support feet
7. Reset switch
8. Threaded plug
9. On/Off switch
10. Mains power connection
11. Axle shaft
12. Washer
13. Wheel sleeve
14. Lock nut
15. Holes of the support feet
16. Groove
17. Threaded bolt
18. Aluminium cover
19. Blade
20. Countersunk screw
21. Collecting bag
a. Wrench
b. Allen wrench
c. Stopper

3. Scope of delivery

• Machine body
• Support feet (2x)
• Axle shaft
• Lock nut (6x)
• Wheel sleeve (2x)
• Washer (2x)
• Wheel cap (2x)
• Wheel (2x)
• Collecting bag
• Wrench
• Allen wrench
• Stopper
• Instruction Manual

Accessories:

• replacement collecting bag
