Page GB-12
Assembly
Attaching the exhaust hood
(5)
(6)
1. Screw 2 fixing screws into the upper
screw plugs so that both screws are pro-
truding about 1 cm.
2. Carefully hang the Exhaust hood (1) on
the keyhole openings (5) on the two up-
per screws.
(5)
)
)
(1)
3. If necessary, remove the Exhaust hood
again and loosen or tighten the screws
in order to ensure that it is flush with the
wall.
Please note: The Exhaust hood is not yet
secured against falling down.
(7)
4. Fold the cover (7) up.
5. Slide the lock (8) of the grease filter (9) to
the side and carefully remove the grease
filter.
2x
6. Screw two fixing screws to secure the
Exhaust hood through the securing open-
ing (6) into the prepared dowels and
screw the Exhaust hood to the wall.
(8)
(9)
(6)
