category. If necessary, move the bumpers anteriorly (stiffer) or posteriorly (softer) to get the desired stiffness. For permanent
placement, clean off the pre-applied adhesive with acetone and adhere bumpers using cyanoacrylate glue.
Distance from the rear
Foot size (A)
end of the sole (B)
22-25 cm
29 mm / 1,14''
26-28 cm
35 mm / 1,4''
29-31 cm
48 mm / 1,9''
11.
TROUBLESHOOTING
CONCERN
• Foot flat occurs too rapidly
• Toe feels excessively stiff
Heel too soft
• Knee hyperextension
• Rapid knee flexion, instability
• Heel to toe progression too fast
Heel too hard
• Lack of energy return sensation
Foot module
• Flat spot in rollover motion at slow cadences
too stiff
• Clicking noise at initial contact
Foot module
• Excessive toe deflection with high impact
too soft
activity
12.
WARNINGS
In case of damaged packaging, check the integrity of the device.
Never use the foot without a foot shell.
Never loosen the pyramid fastening screws.
The patient must inform their prosthetist if they gain or lose significant weight.
Always use the foot with a sock and shoe. Failure to adhere to this advice may cause product failure, as well as serious
injury.
Make sure that the foot and inside of the foot shell are free of impurities (e.g., sand). The presence of impurities causes
the graphite parts to wear out. Clean the foot according to the instructions (see §16).
After swimming, using in water or if splashed by a liquid, the foot must be cleaned (see §16).
If the patient notices any abnormal behavior or feel any changes in the characteristics of the device (noise, play, excessive
wear...), or if the device has received a severe impact, they should stop using the device and consult their prosthetist.
Failure to follow the instructions for use is dangerous and will void the warranty.
13.
CONTRAINDICATIONS
Use for a patient whose maximum weight (load carrying included) may exceed 166 kg / 365 lbs
Use for activities associated with a risk of significant impact or excessive overloading
14.
SIDE EFFECTS
There are no known side effects directly associated with the device.
INSTRUCTIONS FOR USE
SYMPTOM
SOLUTION
• Shift socket anteriorly in relation to the foot
• Attach stiffening bumpers. See section 10 above
for installation details
• Shift socket posteriorly in relation to the foot
• Verify appropriate foot module category
• Consider a lower category foot module
• Consider a higher category foot module
Page 3 of 4
IFU-01-036
