Never immerse the vacuum cleaner or the adapter in water or any other liquid and do not place it under
running water.
During regular cleaning also clean the wheels and their bearings.

Cleaning the rotary brush

If the rotary brush is blocked for some reason, the vacuum cleaner will move more slowly. In this case, the
rotary brush must be cleaned.
1. Press the rotary brush pull-out lock.
2. Remove the brush from the floor nozzle and clean it, then put it back in place.
TROUBLESHOOTING
Problem
The handheld vacuum
cleaner does not work
The motorized brush of the
floor vacuum cleaner does
not work.
The handheld vacuum
cleaner does not collect dirt
or has weak suction power.
Dust escapes from the
handheld vacuum cleaner.
The battery does not hold
the charge.

TECHNICAL DATA

Vacuuming dry and wet dirt
Washable filter HEPA H12
Charging time: appr. 4.5 hours
Operation time: 22 minutes at maximum power, up to
50 minutes at low level
Dust container capacity: 0.5 l
Charging battery indicator
8
Cause
• The battery is empty.
• Faulty battery (does not hold the charge).
• Dirty contacts between the appliance and
the charging contacts.
• Charging adapter is connected to an outlet
without voltage.
• The charger is connected.
• The blade fan wheel is clogged with dirt.
• Broken belt.
• The handheld vacuum cleaner is not properly
inserted.
• Dust container is full.
• You must clean or replace the dust container
filter.
• The vacuum cleaner battery is empty.
• Dust container is full.
• Incorrectly installed dust filter.
• Torn dust filter.
The battery has reached the end of its service
life (after appr. 1000 charging and discharging
cycles).
Correction
• Charge the appliance.
• The battery is dead.
• Clean the contacts.
• Check the fuses, use different outlet.
• Disconnect the charger.
• Remove dirt from the blade wheel.
Cu tangled hair, etc. carefully with
scissors.
• Call service.
• Insert the handheld vacuum properly.
• Empty the dust container.
• Remove the filter and make sure the
suction hole is not clogged. Clean or
replace filter.
• Charge the vacuum cleaner.
• Empty the dust container.
• Check proper insertion of the dust
filter.
• Replace the dust filter.
Contact service
Accessories: tapered nozzle, floor mop, 3× cleaning
cushion
Nominal voltage: 22,2 V d.c.
Adapter:
AC 100–240 V ~ 50/60Hz, 0,5 A
27 V d.c. – 500 mA
Batteries:
Li-Ion battery 22,2 V (6 × 3,7 V), 2200 mAh
