ASSEMBLY AND PROGRAMMING INSTRUCTIONS
EquaScan wMIU
Water meter radio module
SCOPE OF DELIVERY
• RF communication module
• Adhesive seal
• Assembly instructions
GENERAL INFORMATION
The EquaScan wMIU V2 serves to integrate the type +m water meters into the
RF
Itron EquaScan radio system for mobile and fi xed network data collection.
The wMIU V2 can be refi tted at any time. The wMIU
RF
existing radio meters in a few simple steps. The wMIU
computer using an inductive head (Ref. No.8090000006) or an EquaScan Master
the EquaScan software.
IMPORTANT NOTICE FOR LITHIUM-BATTERIES
The wMIU V2 contains non-replaceable lithium metal batteries. Do not charge the batteries, do not expose them to
RF
temperatures above 100°C or to mechanical stress. Transport regulations for lithium batteries must be observed. The
certifi cates required for transport can be requested from Allmess.
CORRECT DISPOSAL / INFORMATION ON APPROPRIATE PRODUCT DISPOSAL
The crossed-out garbage container symbol on the wMIU
be disposed of separately from household waste so that it can be handled and disposed of properly. All devices that are
subject to the German Electrical and Electronic Equipment Act (ElektroG) must be recycled properly in accordance with
the German Closed Substance Cycle and Waste Management Act (Kreislaufwirtschafts- und Abfallgesetz). The devices
placed on the market by Allmess GmbH can be returned to Allmess GmbH within the framework of the take-back concept.
Please observe the laws in force in your country regarding the return and proper disposal of electrical devices. The product
is potentially not harmful to human health and the environment, but if it is illegally disposed of in the environment, it will have a
negative impact on the ecosystem. Illegal disposal of the wMIU
It is the personal responsibility of the user of the wMIU
Further information on our take-back concept and the return form can be found at
https://www.allmess.de/service/verordnungen-gesetze/
The battery symbol on the wMIU
Characteristics
Power supply
Battery life time
Operating temperature
Protection class
Radio specifi cations
Protocol
Operating mode
Frequency band
V2
RF
V2 can be assembled, installed and integrated into the circuit of
RF
V2 can be programmed and read quickly and accurately via the
RF
RF
V2, if necessary, to delete his private data before disposal.
RF
V2 indicates the end year of the battery life.
RF
3,6 V lithium long-life battery
12 years + 1 year reserve
5°C to 55°C
IP 65
Bidirectional EN 13757-3/-4 wireless M-BUS or unidirectional OMS V4
C2- or C1-Mode
Tx: 868,95 MHz / Rx: 869,525 MHz
. The parameters are programmed using
RF
V2 or on the packaging indicates that the old product must
V2 in the environment is punishable by law.
RF
