3.0 Requirements for
installation
3.1 When using a firewall
Distance from the surround to the firewall:
If the wall behind the product is bricked up with the same
thickness as a firewall the surround may be placed right up to
the firewall.
Standard firewall requirements
The firewall must be at least 100 mm thick and be made of brick,
concrete blocks or light concrete.
Other solutions may be recommended by your supplier.
N.B. In some countries It is illegal to use natural stone as a
firewall.
Installation of a firewall must be according to regulations in
each country.
Note that the entire back panel within the surround must be
covered by a firewall.
3.2 Air circulation requirements
Air shall be allowed to circulate between the insert and the
brickwork.
The areas specified below for the air intake in the base and the
outlet at the top are minimum requirements. This is to ensure
that heat build-up in the surround is acceptable and so that there
is sufficient heat transmitted into the room.
Necessary air openings are:
Base: Minimum 350 cm 2 free opening.
2
Hood: Minimum 750 cm free opening.
The openings required by the SCAN DSA E 400/E405 have been
allowed for.
3.3 Floor coverage requirements
The SCAN DSA E 400 / E 405 have a flush-fitting base plate and
therefore no extra floor protection is required.
Any flammable flooring material must be removed from the area
under the stove and floor plate.
3.4 Front plate requirements
In front of the stove a plate made of steel or other non-flammable
material should be used.
The depth of this plate depends on the laws and regulations in
each country.
All manuals and user guides at all-guides.com
4.0 Adjustment and treatment
4.1 Painting the surround
All surrounds are delivered unpainted.
Painting may take place the day after installation. Use latex
paint. If a slight surface texture is desired mix a little tile cement
in with the paint.
4.2 Cracks
After several month's usage small cracks may appear in the joints
due to settling. These cracks can easily be repaired:
•
•
•
•
Open up the cracks with, for example a screwdriver, in order
to give more space for the filler.
Remove any dust with a vacuum cleaner.
Inject an acrylic filler into the cracks and smooth over with a
wet soapy finger.
After a couple of days the join may be painted.
