You need a soft foam underlay or an underlay made of a similar material as you
have to tilt the appliance by max. 45
1. Remove the 4 covers on the top (flathead
screwdriver). Unscrew the screws (crosstip-
screwdriver).
2. Remove the 3 screws of the top hinge (8 mm).
Remove the hinge. Remove the door.
3. Remove the hinge pin (A) and fix it on the reverse
side.
4. Remove the hinge insert plate from the bottom of
the door and fix it on the opposite side.
5. Tilt the appliance by max. 45
and the screws securing the right hand hinge plate,
and the fixing plate.
6. Remove the hinge pin (1) and fix it in position 2.
Fix the hinge on the opposite side. Fix the foot.
0 while working.
0 and remove the feet
