INSTALLATION
Installation
1 Silicone seal ring
2 Union nut
3 Connection pipe
4 Union nut for compression fitting
5 Locking ring
6 Ring insert
7 Compression seal ring
8 Tap lever
9 Tap body
10 Silicone seal ring
11 Diverter valve: Spout and hand shower (MEBD only)
12 Spout
13 Aerator
14 Silicone seal ring (MEBD only)
15 Retainer (MEBD only)
16 Flow limiter
17 Hose (MEBD only)
18 Hand shower (MEBD only)
19 Flat seal ring
20 Tap extension
21 Wall bezel
22 Push rosette
23 Anchor pin
Notice
If possible, flush the new or repaired cold water pipes
before installing the tap.
www.stiebel-eltron.com
6.1

Cold water connection to tap

f Seal the thread of the tap body using hemp or Teflon tape.
f Screw the tap extension together with flat gasket to the tap
body.
f Slide the wall bezel over the tap extension.
f Seal the thread of the tap extension using hemp or Teflon
tape.
f Fit the tap body together with wall bezel, tap extension and
flat gasket to the cold water pipe. Align the tap body horizon-
tally when doing so.
