7. Press the STOP button to return to normal mode.
8. Play the tape a few seconds then press the SLOW
button again and make sure there is no noise in
the screen.
(For the LP mode put adjustment at the same
adjustment way as SP mode.)
Notes:
© Self-recorded tape means a cassette whose
program was recorded by the unit being
adjusted.
@ The TV program will not be recorded if RCA or
21pin plugs are pluged in to the AUDIO/VIDEO
input terminals.
ADJUSTMENT OF FV (False Vertical Sync)
OF STILL PICTURE
Measuring Colour TV monitor
instrument
Playback still
Cassette Self-recorded tape (SP mode)
(See Note below @)
Control Tracking control buttons (+) or
(-)
Specification No vertical jitter of picture
1. Play a cassette which was recorded by the unit in
SP mode.
2. Press the PAUSE/STILL button to freeze the
picture.
3. Look at the monitor screen and adjust (+) or (—)
TRACKING buttons so that the vertical jitter of
the picture to be minimized.
4. Play and freeze the self-recorded tape in SP
mode and make sure vertical jitter of the picture
is not noticeable.
(For the LP mode put adjustment at the same
adjustment way as SP mode.)
Note:
© Self-recorded tape is a cassette whose program
was recorded by the unit being adjusted.
