CONNECTION OF APP+ TO OBSOLETE RIB (OR NOT RIB) CONTROL PANELS WITH OPEN GATE
SIGNAL
CONNECTION APP+ TO NOT RIB CONTROL PANELS
R => Relay with clean contact activated by the control panel (or magnetic / electromechanical
limit switch installed when the gate is closed). Used by APP+ to know the gate position
(closed / open).
Depending on the status of the contact at rest (NO or NC) it is possible via command in Advanced
Parameters of the RIB GATE App, to invert or not the signals so that they are shown correctly by
the APP (closed / open)
CONNECTION APP+ TO AN ELECTRIC LOCK - WITH ON/OFF SIGNALING
R => 12Vac relay with minimum contacts 5A
CONNECTION APP+ TO CONTROL UNITS RIB 2019
L1, L1 24V, B2, B2 24V, B2D 24V, P1, P1 24V
A+
A-
K-BUTT
COM
COM
SIGNAL
RIB GATE
To activate this card, simply download the RIB GATE App from the Apple Store or Google Play and
⚠
register yourself as an installer.
In an installation company, the first Installer / Owner who registers will
receive a company code. This company code must be used for the registration
of all the installers of the same company so that they will be able to share all
the systems built.
⚠
To pair your smartphone with the panel in which you have connected the APP
+ card code APP8054 or just the APP + card, register as "Installer" in the RIB
GATE App you downloaded on your smartphone. Only as an installer can you
authorize users' smartphones to use this bluetooth card.
12/24V ac/dc
Once you have registered and feeded the system, the card will appear in the smartphone APP.
Following the various steps you will then be able to enable the remote controls and smartphones
of the various users.
COM
You can give permissions such as:
START
- Administrator / Owner of the house.
- User.
- Temporary user.
R
RIB Cloud => https://cloud.ribind.it
With personal account Installer - Administrator / Owner of the house
Via web browser it is possible to:
- access to your personal web space where all the registered systems are present.
- insert the installer logo and the installer data (the Users app is updated automatically by
uploading the installer logo and its contact details).
- Automatically download data to the cloud every time the Bluetooth 4.2 signal connects (if the
Wi-Fi signal is not present).
- have access to all the features in the RIB GATE App. They will be available directly to those who
are enabled to interact with the module (installer, administrator / landlord).
- access the log to check people's entries/exits and at what times (Wi-Fi + Clock modules).
12V ac
R
13
